Reed Instruments R3000SD - Instrument Description

6
Instrument Description
pH/ORP Meter
SD Series Data logger
TIME LOG/SET
SAMPLING
CHECK
FUNCTION
POWER
HOLD
ESC
R
E
C
E
N
T
E
R
R3000SD
2
3
4
6
5
A
B
7
8
9
10
11
12
13
14
1
15
16
17
1. LCD Display
2. POWER/Backlight Button
 
4. TIME Button
5. SD Card Slot
6. HOLD/ESC Button
7. REC/ENTER Button
8. Down/ Button
9. /SET/
CHECK Button
10. RS-232 Output Jack
11. Reset Pin
12. Power Adapter Input Jack
13. Tripod Mounting Screw
14. Battery Cover
15. Kickstand
16. pH/ORP Electrode Input
(BNC) Jack
17. Temperature Probe Input Jack
