REED R8085 - Instrument Description

8
Instrument Description
3
4
5
14
13
12
9
6
7
8
10
15
16
R8085
Noise Dosimeter
11
ESC
HOLD
RUN/
PAUSE
DUR/BEG TIME
SET LOG
ENTER
FUNC.
UNLOCK
1. LCD Display
2. HOLD Button
3. Power/ESC/Backlight Button
4. Up/Duration/Begin/Fast/
Slow/dB Range Button
5. FUNCTION/SET Button
6. Microphone Input Jack
7. RUN/PAUSE Button
8. Down/A/C/TIME Check Button
9. ENTER/LOG Button
10. Wrist Strap Anchoring Point
11. RS-232 Output Jack
12. Tripod Mounting Screw
13. Battery Cover
14. Battery Cover Screw
15. Microphone
16. Microphone Plug
