Technical Data 39
PowerUnit
REFUsol 100K
982059/02
2020-11
EnglishDeutsch
DC nominal power
85.5 kW 90.5 kW 102.5 kW 102.5 kW
MPP tracker
1
DC connection PowerUnit-to-ConnectionBox
1 Plus, 1 Minus: Connector with button activated coupling
AC DATA
AC nominal power
83.3 kVA 88 kVA 100 kVA 100 kVA
AC rated voltage
380 V 400 V 460 V 480 V
AC nominal voltage
315, 380, 400, 415, 440, 460, 480 V
AC voltage range
180 … 528 V
AC grid connection / grid types
3 phases, PE / TN-C, TN-S, TN-C-S, TT
Nominal power factor / range
1 / 0.3i … 0.3c
Rated frequency / frequency range
50, 60 Hz / 45 … 65 Hz
Max. AC current
128 A
Max. AC short circuit current
64 A (3 period average)
Inrush current (peak / duration)
25 A / 0.5 ms
Max. THD
< 3 %
Tab. 12: Technical data REFUsol 100K
DC DATA
