Technical Data40
PowerUnit
REFUsol 100K
982059/02
2020-11
Max. efficiency
98.3 % 98.4 % 98.7 % 98.7 %
European efficiency
97.9 % 98 % 98.5 % 98.5 %
Night-time power loss
< 1 W
Maximum admissible external AC fuse
160 A, gG, U
N
= 500 V
Peak current (Ip) / Initial short circuit current
(Ik“) according to IEC 60690-0
128 A / 325 A
AC connection PowerUnit-to-ConnectionBox
connector with Button Activated Coupling
Tab. 12: Technical data REFUsol 100K
DC DATA
AMBIENT CONDITIONS
Cooling
Smart active cooling
Max. temp. for nominal power
45 °C
Ambient temperature
-25 … +60 °C
Rel. air humidity
0 … 100 %
Max. elevation, above sea level
3 000 m
Noise level
< 70 dBA
