Rega ELEX MK4 User Manual

10
EN
SPECIFICATIONS
AMPLIFIER OUTPUT
THD+Noise (at 1dB below clip into 8Ω measurement bandwidth 22Hz to 22kHz) A-weighted
Bandwidth (at 80W into 8Ω)
Input Sensitivity (for 72W into 8Ω)
Output Sensitivity (at rated inputs)
Line Inputs 10Hz (-1dB) to 65kHz (-3dB)
Line Inputs 2-5 164mV load 10k
Input D1 S/PDIF Isolated 0.5V 75Ω Co-axial
Dimensions (WxHxD) 432 x 82 x 340mm (17 x 3.25 x 13.4in)
Power Supply AC supply 230V / 220V / 115V / 100V nominal ±10%
Fuse Ratings T3.15 AL 250V - 230V 50Hz / 220V 60Hz
T5 AL 250V - 115V 60Hz / 100V 50/60Hz
Supported Sampling Rates 32, 44.1, 48, 88.2, 96, 176.4, 192kHz
THD+Noise (DAC Output from Tape Out) Typically 0.004% at 1kHz
Pre-amplier Output 625mV
Line Inputs Typically 0.005% at 1kHz
Phono Input 15Hz (-3dB) to 65kHz (-3dB)
Phono Input 1.6mV load 47k in parallel with 220pF
Record Output 164mV
Input D2 S/PDIF Optical Toslink
Supported Bit Depths 16 to 24 bit
Weight 11kg (24.3lbs)
Power Consumption 250W at 1dB below clip into 8Ω
Remote Batteries AAA (1.5V) x 2
Power Amplier Gain 31.6dB
RIAA Accuracy Better than ±0.5dB 100Hz to 20kHz
Preamplier Output Typically 0.002% at 1kHz
Power Amplier Output (at rated 230/115V supply voltage) 72W per channel into 8Ω
90W per channel into 6Ω
Note: Continued high level use into loads of 6Ω or less may cause
the case to exceed 40°C above ambient temperature and activate
the thermal shut down.
Headphone Output No Load 11.3V
300Ω 8.1V
54Ω 3.6V
32Ω 2.4V
Source Impedance 109Ω
DISTORTION
FREQUENCY RESPONSE
SENSITIVITY
DIGITAL INPUTS
DIMENSIONS AND WEIGHT
POWER

Rega ELEX MK4 Specifications

General

Line Input Sensitivity	210 mV
Input Impedance	47 kΩ
Power Output	72 W per channel into 8 Ω
Inputs	1 x Phono
Outputs	Record Out, Headphone Out
Input Sensitivity	210 mV (Line)
Total Harmonic Distortion	<0.007%
Dimensions	432 x 82 x 340 mm
