Chapter 4
4-8
FUSE FUNCTION AMPS TYPE PLACE
Accessory 1 (If Included) 15 Fuse Dash Fuse
Box
Accessory 2 (Not Available) 15 Fuse Dash Fuse
Box
Bilge Pump Manual 7.5 Fuse Dash Fuse
Box
Bilge Pump Automatic 10 Fuse Engine
Blower 10 Fuse Dash Fuse
Box
Cockpit Lights 10 Fuse Dash Fuse
Box
Actuator- Protects Dash Switching 10 Breaker Actuator Box
Actuator- Port or Starboard Gear 25 Fuse Actuator Box
Main Breaker- Battery Switch to Helm 50 Breaker Battery
Switch Area
Docking Lights (Not Available) 15 Fuse Dash Fuse
Box
Fresh Water 7.5 Fuse Dash Fuse
Box
Garmin (Not Available) 10 Fuse Dash Fuse
Box
Horn 10 Fuse Dash Fuse
Box
Ignition Breaker 20 Breaker Ignition
Panel
Navigation / Anchor Lights 10 Fuse Dash Fuse
Box
Stereo Memory Fusion Feed 15 Fuse Underneath
Dash
Stereo Memory Main Feed 15 Fuse Engine
Stereo Performance (Optional) 40 Breaker Battery
Switch Area
12 Volt Accessory 15 Fuse Dash Fuse
Box
**Typical Fuses
