SEAT OPERATION- HELM W/ BOLSTER
e bucket helm seat features forward and
a movement, as well as a swivel motion
that allows the seat to pivot, and a ip up
bolster cushion that allows any user to
control his/her comfort and position.
To adjust the fore and a helm seat position:
Loosen black fore & a adjustment handle A located amidships
by turning counter clockwise. en slide the seat to the desired
location and retighten the handle.
To swivel the seat:
Loosen handle C. Pull up on swivel handle B to unlock the detention
system. While the detention system is unlocked, pivot the seat to
the desired position. Be sure to lock the swivel handle B in the
de-tented position by pushing down on the handle and nding a
locked position. Tighten handle C. DO NOT run the vessel unless
the swivel is in the locked position.
TO PREVENT BODILY INJURY PERIODICALLY CHECK AND
TIGHTEN THE MOUNTING BOLTS BETWEEN THE SEAT SLIDER
AND THE BUCKET SEAT BOTTOM. ALSO, CHECK THE FLOOR
INSERT BOLTS.
