CHAPTER 7
7-20
Fuses
The dash features individual fuses for onboard equipment. Should an
overload develop, that individual fuse will “blow”. After determining
the system fault, replace the fuse with the exact size. The fuse panel is
located at the helm area. Carry extra fuses for emergencies. Fuses can
be purchased from a marine store or you Regal dealer.
There is an access under the dash to many of the wires. On the 2250
there is an access plate at the cabin forward bulkhead. Periodically
check the mounting blocks on all wiring components to make sure all
connections are tight. Refer to the illustration for more information.
TYPICAL FUSE PANEL
FUSE BLOCK
