CHAPTER 6
6-12
Canvas Enclosure
To install the optional canvas enclosure follow these steps:
1. Install the bimini top per previous page.
2. Zip the windscreen to the bimini top. Then attach the windscreen
to the windshield snaps. It may be necessary to unzip a portion of the
top to access the snaps.
3. Next, install the port and starboard side curtains. They may be
marked for easy identifi cation. If not, a visual inspection will indicate
their port or starboard location.
4. Finally, install the aft curtain to the bimini top rear section and zip it
in place. Finish installing any remaining snaps as you exit the boat.
5. Do not operate the vessel on the water or highway with the canvas
enclosure in place.
6. When breaking down the canvas enclosure make sure each canvas
piece is dry especially the clear window glass material. Roll all canvas
parts before stowing them. Folding clear glass canvas parts could permanently
damage them.
