Battery Management Panel
The battery management panel is located under the starboard aft side
seat againist the hullside. Below is a description of the system and an
operational footprint.
The following items are controlled by the port battery. They include
the port battery charger, and the forward bilge pump.
The following items are controlled by the starboard engine battery.
They include the aft bilge pump, shower sump pump, and starboard
battery charger.
The following items are controlled by the house battery. They include
the house battery charger, stereo memory, CO monitor, halon
(automatic fi re extinguishing system and accessory breakers.
Note that all items except the stereo amplifi er, CO monitor, halon, and
accessory breakers are constant hot circuits even with the appropriate
battery switch off.
Note that the cabin main, dash main, windlass, port steering and
starboard breakers are only on when the battery switch is turned to
the on position.
The engine battery switch in an emergency start situation where
there is low battery current can be turned to the yellowed portion
of the switch and at that point the engine can be started by
using back up house battery current.
