Auxiliary Equipment Operation
To change a hanging locker light bulb follow these steps:
Remove the lens cover from the lamp base. There is a
tab on the bottom of the lens cover. Push the lens cover
at this point to remove it.
Remove the defective bulb.
Replace the bulb with a 12 volt halogen bulb type
# 563.
Reinstall the lens cover by snapping it in place.
HANGING LOCKER LIGHTS
READING LIGHTS
To change a reading light bulb follow these steps:
Remove the lens cover from the lamp base by turn-
ing the lens cover counterclockwise slightly and while
in this position pull the lens cover out at the lamp body
notches.
Remove the defective bulb.
Replace earlier style fi xture with a 12 volt halogen bulb
# 10WXH. The later style bulb pulls straight out. Replace
with a 12 volt 18 watt bulb.
Reinstall the lens cover by fi rst lining it up with the
notches on the lamp body. Let the lens cover/body enter
the notched area and then lock it in place by turning the
lens cover clockwise.
Lens
Cover
EARLIER STYLE
Lens Cover Removed
Notched Area Here
Under Cover
