Chapter 4
TYPICAL 12 VOLT HELM BREAKER SUB PANEL DESCRIPTION
HORN- protects the air horn located on the hardtop.
PANEL LTS- protects the helm (dash) back-lit icons.
NAV LTS- protects the port and starboard deck naviga-
tion for night cruising.
WINDSHIELD VENT- protects the fresh air wind-
shield vents.
DECK LTS.- protects the deck light circuit.
UNDERWATER LTS.- protects the transom mounted
light (under platform) circuit.
PORT WIPER- protects port windshield wiper circuit.
STBD. WIPER- protects the starboard windshield wip-
er circuit.
SUNROOF (CONVERTIBLE HARDTOP)- pro-
tects the motor that regulates the sunroof movement
forward or aft.
COCKPIT LTS.- protects the cockpit installed light cir-
cuit.
HARDTOP LTS.- protects the sunroof ceiling lights.
BILGE LTS.- protects the garage and engine room light
circuitry.
FUEL XFER- protects the sump mounted transfer
pump.
COCKPIT 12 VOLT OUTLET- protects the accessory
plug circuitry.
CAPTAIN SEAT UP/DOWN- protects the helm seat’s
up/down movement circuitry.
CAPTAIN SEAT FWD/AFT- protects the helm seat’s
forward and aft movement circuitry.
TV HATCH- protects the optional cockpit television
overhead cabinet lid.
COCKPIT FRIDGE.- protects the cockpit refrigerator
circuit.
TRIM TABS- protects the transom mounted electric-
hydraulic trim tab circuit.
WINDLASS- protects the deck mounted foot petals.
COCKPIT STEREO- protects the dash stereo power
circuit.
STEREO AMP- protects the stereo amplifi er.
PORT WINDOW WASHER- protects the motor cir-
cuitry.
STBD. WINDOW WASHER- protects the motor cir-
cuitry.
DE-FOG FAN- protects the windshield defogging sys-
tem.
CO MONITOR- protects separately the 3 CO detectors
located in the forward, salon and aft staterooms.
ACC. 1- protects the accessory equipment circuit.
ELECTRONICS- protects the dash electronics switch.
VHF- protects the marine radio circuitry.
COCKPIT DVD- protects the DVD player.
GAS VAPOR- not used since both vessels use diesel.
