TYPICAL 12 VOLT HELM BREAKER SUB PANEL DESCRIPTION (CONTINUED)
PLOTTER 1- protects the GPS/Plotter starboard dash
mounted circuitry.
PLOTTER 2- protects the GPS/Plotter port dash
mounted circuitry.
RADAR- protects the deck mounted radar circuitry.
SEA KEY- not used.
SIRIUS WEATHER- protects the satellite weather cir-
cuit.
CAMERA 1- protects a camera circuit.
CAMERA 2- protects a camera circuit.
CAMERA 3- Currently not used.
