Manual CORRIGO C-SERIES 2000.09
Configuration
Configuration implies the commissioning setting of all the parameters in the
CORRIGO. Parameters are set using script.
Configuration codes
There is also the option of setting parameters by means of two configuration codes.
This function is particularly useful and time-saving when a number of controllers are
to be configured in the same way.
The first thing to be shown when the configuration menu is opened is the setting of
the control function.
Using the arrow up button the two configuration codes will be displayed and the
arrow down button will give the parameters of the other configurations in script.
The code digits in the configuration code correspond to the script parameters below
in numerical sequence. This means that the first digit in CONFIG.CODE1
determines which control function the controller is to work with. The second digit
refers to heater type etc.
Before the corresponding selection in the script parameters there is a digit which
corresponds to the code number in the configuration code. See the details below.
Tables for configuration code
There is also a special table to facilitate the choice of configuration code. This is
always supplied together with the CORRIGO instruction sheet.
In the table all the configuration parameters are shown as well as the selections
that can be made. Basic selections are marked in bold type.
By going through the parameters and filling in the figures beside the respective
selections the configuration code can be obtained without difficulty. This can also
act as a protocol of settings for CORRIGO.
Automatic restart after changing
When one or more parameters have been changed the controller will restart when
the user leaves the configuration menu.
Control funct. á
0 Suppl.air cntâ
Config code 1 á
0011.1110.0000 â
Config code 2 á
0100.010 â
A Control function
0. Supply air control 0
1. Supply air control with outdoor temperature compensation 1
2. Room control with cascaded supply air temperature control 2
3. Room control with min/max limiting of supply air temp. 3
4. Room control, single sensor 4
5. Supply air control/Room control. Outdoor temp dependent 5
6. Not available for Corrigo C40 -
B Heater type
0. Water heater 0
1. Electric heater 1
C Output Y1
0. Not active 0
1. Heating 1
2. Damper 2
3. Cooling 3
D Output Y2
0. Not active 0
1. Plate heat exchanger 1
2. Rotating heat exchanger 2
3. Not available for Corrigo C40 -
4. Damper 4
5. Heating 5
6. Cooling 6
E Output Y3
0. Not active 0
1. Cooling 1
2. Heating 2
F Frost protection (Water heating only)
0. Not active 0
1. Active on Y1 1
2. Active on Y2 2
3. Active on Y1 with automatic alarm reset 3
4. Active on Y2 with automatic alarm reset 4
G Shutdown mode (Water heating only. Requires outdoor sensor)
0. No 0
1. Yes 1
H Pump stop (Water heating only. Requires outdoor sensor)
0. No 0
1. Yes 1
I Function not available for Corrigo C40
This code must always be set to 0 0
J DX-cooling
0. No 0
1. 1-step 1
2. 2-step 2
3. 3-step binary 3
K Cooling recovery
0. No 0
1. Yes 1
L Free cooling
0. No 0
1. Yes 1
CONFIGURATION-CORRIGO C40 A B C D . E F G H . I J K L
Configuration code 1 . .
