External Display, ED9200 23
Chapter 5 External Display, ED9200
Functions
ED9200, external display, is a separate unit for display and configuration that can be
connected either to an EXOcompact or to an EXOflex via two different electrical interfaces.
The dialog window that is an LCD-Display with background lighting has 4*20
characters. The character set is European/Cyrillic.
Environmental resistant overlay with a keypad containing navigation and entry keys
with click feeling
Software controlled alarm LED and indication of communication and power supply.
Mounting can be made on panel or the like.
With a sealant kit, the sealing class will be IP65 when mounted on a panel or the like.
About connection to EXOflex, see the EXOflex documentation.
When ED9200 is connected to EXOcompact, functions like software controlled view
angle, background lighting, and buzzer are missing. To get these properties you have
to connect the display to EXOflex! In addition to that, the communication distance is
limited to maximum 10 m when connection is made to EXOcompact. The
corresponding distance for EXOflex is 200 m.
