24 External Display, ED9200
Indications
The indication LEDs have the following functions:
Designation Function Color
P Power supply. Green
C Communication. Green
There is one or more unacknowledged alarm(s). Flashing
red
There is one or more remaining, acknowledged alarm(s). Fixed red
You are in a dialog box where it is possible to switch to
change mode.
Flashing
yellow
î
Change mode. Fixed
yellow
Controller Requirements
The handling of ED9200 in EXOcompact/Corrigo E requires EXOreal 2.8-1-29 or later.
Specifications
Power supply via communication cable............. internal from EXOcompact/Corrigo E
Display............................................................................ 4*20 alphanumeric characters, LCD
character height ..........................................................................................................4.75 mm
background lighting..................................................................... yes, save mode/active mode
Sealing class..................................................................IP41 in basic design, IP65 as option
Connection cable................................................3 different types with RJ12 fast connector
EK10................................................................................................................................1.5 m
EK12...................................................................................................................................3 m
EK14.................................................................................................................................10 m
Maximum cable length is 10 m.
