30 External Display, E-DSP
Indications
The indication LEDs have the following functions:
Designation Function Color
There is one or more unacknowledged alarm(s). Flashing
red
There is one or more remaining, acknowledged alarm(s). Fixed red
You are in a dialog box where it is possible to switch to
change mode.
Flashing
yellow
î
Change mode. Fixed
yellow
Specifications
Power supply via communication cable.............................. internal from EXOcompact
Display............................................................................ 4*20 alphanumeric characters, LCD
character height ..........................................................................................................4.75 mm
background lighting..................................................................... yes, save mode/active mode
Sealing class................................................................................................................... IP41
Connection cable................................................2 different types with RJ12 fast connector
E-DSP-3 (corresponds to EK12) .......................................................................................3 m
E-DSP-10 (corresponds to EK14) ....................................................................................10 m
Maximum cable length is 10 m.
Connections
See ED9200.
Mounting
On panel, wall, or 60 mm device box.
