I/O C152D C282D
AI 4 4
DI 4 8
UI, (AI or DI selectable) 4
AO 3 5
DO, type mosfet, AC or DC output 4 7
Sum I/O 15 28
Port 1 (RS485)/ galvanically insulated:
Yes/No Yes/No
Internal Display & keypad Yes Yes
24VDC output (+C) Yes Yes
Other features:
Support for external display, ED9200,
ED9100 & E-DSP (HMI)
No No
Variants for ordering,
communication ports:
TCP/IP, T
(replaces the RS485 Port 1)
C152DT C282DT
Port 2 (RS485 port) galvanically
insulated:
Yes/Yes Yes/Yes
LON Port
Based on FT 3150 Smart Transceiver from Echelon (two-wire connection).
Suitable LonMark function profile is selected from EXOapt’s library to match the external
LON equipment function profile. The connection between the SNVT:s of the function profile
and the corresponding EXOL variables are predefined in a so-called .dpe file that is
downloaded via the EXOline port.
The selected function profile is loaded as an .apb file through the LON network. The
accompanying variable description file (.xif file) is used by LonMaker for variable binding
and integration purposes.
FT 3150 Neuron acts as a gateway out on the LON network.
A maximum of 62 SNVTs can be handled in the predefined function profiles.
The cable to use, max cable length, network building, terminations etc. should be performed
according to directions from Echelon.
