REI TALAN 3.0 User Manual

BASIC TALAN OPERATIONS
7
BASIC TALAN OPERATIONS
Battery Charging and Power Control
The TALAN has a built-in battery charger. To charge the battery, simply plug the power adapter
into the AC adapter port while the battery is in the TALAN.
Expected charge time: 1.5 hours with the TALAN off (3+ hours with TALAN operational).
Expected run time (on battery): 4 hours.
Note: It is recommended that the TALAN battery be recharged on a regular basis during
extended periods of storage (3 months or more) to prevent damage to the battery.
Additionally, when storing TALAN for long periods (1 month or more), it is recommended that
the battery be removed from the unit and placed in the storage compartment in the case.
Storing the TALAN with the battery in the unit can deplete it more rapidly, potentially
shortening the life of the battery.
Updating the Software and Firmware
 Software updates (in the form of a .FIX file) will be available on-line or by contacting REI at
sales@reiusa.net.
 Place the downloaded .FIX file on a USB thumb drive.
 Plug the thumb drive (with .FIX update file) into the TALAN.
 Press the F6 (System) button and choose Update from the pop-up menu.
 Highlight the .FIX file and press the OK button.
 The TALAN will now update the software/firmware. Follow any on-screen directions as the
TALAN may need to be restarted for the update to take effect.
 Remove the thumb drive and save the .FIX file as a back-up.
Note: Check REI’s website or the REI TSCM Newsletter for software update notification.
If you have any questions, contact REI at sales@reiusa.net.
Saving Screen Shots to Thumb Drive
To assist in report writing, the TALAN provides the ability to capture screen shots from the
TALAN display. These images are created as BMP (bitmap) images and stored to a thumb drive.
To use this function, the thumb drive must be inserted in the USB port on the front of the
TALAN. Press the following key sequence to store the current screen image:
 SHIFT
 HELP
If the screen shot is successful, the TALAN logo in the upper right corner will cycle through
background colors of green and yellow before returning to black. If the screen shot is not
successful (e.g., no USB drive), the TALAN logo will cycle through background colors of blue and

REI TALAN 3.0 Specifications

Control System

primary computer	32 bit RISC processor, 520 MHz
internal memory	64 MB SDRAM (OS), 64 MB Flash
external memory	Compact Flash Type III, USB mass storage

Digital Multimeter

sample rate	500 msec
AC/DC volts	0 to 250V Maximum
AC/DC current	0 to 300mA Maximum
resistance	0 to 42MΩ
capacitance	50pF to 40µF

Power System

external input	15VDC @3A
universal power supply	100-240VAC, 50-60Hz
removable battery	Rechargeable Lithium ion, 4-hour runtime

Mechanical

dimensions	10.0 in x 12.9 in x 2.7 in (25.4 cm x 32.8 cm x 6.9 cm)
weight with battery	6 lbs (2.7 kg)
case dimensions	5.4 in x 14.9 in x 19.5 in (13.7 cm x 37.8 cm x 49.5 cm)
loaded case weight	19.0 lbs (7.1 kg)
operating temperature	0°C to +50°C

Harmonic Locator Probe

operational frequency	225 kHz & 450 kHz
antenna type	Balanced Loopstick
headphone audio output	16Ω, 105dB SPL limited
battery	9V Alkaline
run-time	10 hours average, 22 hours (headphones)
size	17.5 in x 1.5 in (44.45 cm x 3.8 cm) stored, 63.75 in x 1.5 in (162 cm x 3.8 cm) fully extended
weight	1 lbs (.5 kg)
