TESTING CONCEPTS AND RECOMMENDED TEST SEQUENCE
24
Test Types
When executing the tests under the Sequencing Mode, the tests that the TALAN will perform
includes those selected using the TEST TYPE selection. The TALAN will automatically utilize
default settings for the various test functions.
The TEST TYPE can be configured by the user as necessary. There are “quick set” buttons for
Block, Phone, ALL, and NONE. These buttons will set the appropriate set of tests for VDC (Volts
DC), VAC (Volts AC), RES (Resistance), CAP (Capacitance), IDC (current DC), and IAC (current
AC). Below is an example of the Stage 1 (On-Hook) DMM tests where the TEST TYPE was set to
All Pairs and All Wires for all test types.
Subsequently, when START is pressed, the TALAN will test all pairs and wires for all tests.
The default factory settings for BLOCK and PHONE are as follows:
