1 6 pressure plate screws
2
Spring ring
3 Belleville spring
4
Slider ring
5 Pressure plate
6
Throw-out bearing and washer
7 Clutch pack
8
6 Drive pins
Be careful that the drive pins
do not fall into the engine
while disassembling.
