Doc ID: 191-7913A
5. Use a hammer and large screwdriver to bend down the
tabs of the washer tab, then remove the center clutch nut
with an impact wrench or breaker bar, and a 27 mm
socket.
6. Remove the OE tab washer.
7. Remove the OE center hub from the clutch basket while
leaving the thrust washer on the main shaft.
NOTE: Check that the thrust washer is still on the main
shaft and not stuck to the bottom of the center hub
assembly. Missing the thrust washer will cause clutch
performance issues.
