23
Communications
USER GUIDE
MACH-PROCOM/MACH-PROWEBCOM
MACH-PROCOM
™
/MACH-PROWEBCOM
™
 2007 − 2015 Reliable Controls
®
Corporation. All rights reserved.
FIGURE 17: MACH-PRO(WEB)COM ETHERNET CONNECTION TO LOCAL AND REMOTE WORKSTATIONS
Internet
Internet Router/Switch
Remote Workstation
Local Workstation
MACH-Pro(Web)Sys
MACH-Pro(Web)Com
Modbus-TCP Device
