Reliable Controls MACH-ProCom User Manual

22
 2007 − 2015 Reliable Controls
®
Corporation. All rights reserved.
MODBUS MASTER
Enables the MACH-Pro(Web)Com controller as a master device, communicating with
Modbus RTU protocol to up to 128 Modbus slave devices.
FIGURE 16: AUX-NET PORT CONFIGURED AS MODBUS MASTER
ETHERNET PORT
The MACH-Pro(Web)Com controller features a standard RJ45 socket for connection to an
Ethernet network using standard Category 5 or 5e data cable. The MACH-Pro(Web)Com
controller uses static IP addressing or DHCP, and ships with a default IP address of
192.168.1.200. This address can be modified using the RC-Toolkit MSet Tool. Refer to the
Configuration/RC-Toolkit: MSet Tool/Port Setup/Ethernet section of this document.
According to the Ethernet specification, the maximum distance from device to hub is 100 m
(320 ft).
