BACNET MAIN/SUBNET
Enables MS/TP protocol communications to a maximum of 126 BACnet Master devices or
200 BACnet Slave devices. When defined as a Subnetwork, all Reliable Controls devices
will use automatic BACnet device numbering.
FIGURE 15: AUX-NET PORT CONFIGURED AS BACNET SUB
The BACnet/Sub A option only appears if the MS/TP-Net port is configured as BACnet Main.
MACH-Pro(Web)Com
MACH-ProZone
MACH-ProAir
SMART-Space Controller
AUX-Net
