26. Input for Mains Cord
27. ON/OFF Switch
28. Input for Fader Start Function
29. GND Grounding Screws
30. Phono/Line Assignment Channels A + B
31. Audio Input for Channels A + B (RCA)
32. Audio Input for Return Signal (RCA)
33. Audio Output for Send Signal (RCA)
34. Record Audio Output (RCA)
35. Master Audio Output Asymmetrical (RCA)
36. Master Audio Output Symmetrical (6.3 mm Jack)
50. USB Port (Audio/MIDI Interface)
51. Master Through (3.5 mm Jack)
37. XF MIDI ON/OFF Switch (Crossfader)
38. AUX Input (3.5 mm Jack)
39. Microphone Input (6.3 mm jack)
40. Fader Start Switch for Channels A + B
41. Crossfader Curve Switch
42. Linefader Curve Knob
43. Linefader Curve Switch
44. Headphones Input 1 (6.3 mm Jack)
45. Headphones Input 2 (3.5 mm Jack)
46. FX MIDI ON/OFF Switch (Effect Unit)
47. XF Reverse (Crossfader)
I. Channel assignment indicator
II. BPM indicator
III. X parameter indicator
IV. Y parameter indicator
V. Effect selection indicator
