Reloop IQ2 MIDI - Technical Information




Global Distribution GmbH did not test the following manufacturers’ specications for plausibility
and accuracy:


CD, AUX: .................................................................. 10 kOhm / -14 dBV +/-0.1 dB (200 mV)
Line: .......................................................................... 47 kOhm / -14 dBV +/- 0.1 dB (200 mV)
Phono: ...................................................................... 47 kOhm / -50 dBV +/- 0.1 dB (3.16 mV)
Mic: ........................................................................... 10 kOhm / -50 dBV +/- 0.1 dB (3.16 mV)
Return: ..................................................................... 10 kOhm / -14 dBV +/- 0.1 dB (200 mV)
Master Through: ..................................................... 22 kOhm / 0 dBV +/- 0.1 dB (1 V)

Send: ........................................................................ 1 kOhm / -14 dBV (200 mV) +/- 2 dB
Rec: ........................................................................... 1 kOhm / -10 dBV (316 mV) +/- 2 dB
Master Unbalanced: ............................................... 300 Ohm / 0 dB (1 V) +/- 2 dB
Master Balanced (Load = 600 Ohm): ................. 600 Ohm / + 2.22 dBm (1 V) +/-2 dBm
Phones (Load = 32 Ohm): ..................................... 10 Ohm / 0 dBV (1 V) +2 /-3 dB

Line, CD, AUX: ......................................................... 20 Hz – 20 kHz +2/-3 dB
Phono: ...................................................................... 20 Hz – 20 kHz +2/-3 dB (RIAA)
Mic: ........................................................................... 20 Hz – 20 kHz +2/-3 dB
Master Through: ..................................................... 20 Hz – 20 kHz +2/-3 dB

Line, CD, AUX: ......................................................... < 0.085% 20 Hz – 20 kHz
Phono: ...................................................................... < 0.085% @ 1 kHz
Mic: ........................................................................... < 0.085% @ 1 kHz
Master Through: ..................................................... < 0.085% 20 Hz – 20 kHz

Line, CD, AUX: ......................................................... > +6 dBV
Phono: ...................................................................... > -30 dBV
Mic: ........................................................................... > -30 dBV
Return: ..................................................................... > +2 dBV

Send: ........................................................................ > + 3 dBV (1.42 V)
Master: ..................................................................... > +16 dBV (6.31 V)
Rec: ........................................................................... > + 8dBV (2.52 V)
Phones: .................................................................... > +3 dBV (1.42 V) Load = 32 Ohm

Line, CD, AUX: ......................................................... > 85 dB
Phono: ...................................................................... > 85 dB
Mic: ........................................................................... > 85 dB

Line, CD, AUX, Phono: ........................................... > 63 dB @ 1 kHz between left and right channel
................................................... > 85 dB @ 1 kHz between channels

Mic: ........................................................................... 12 +/-2 dB, -12 +/-2 dB @ 100 Hz
............................................................................. 12 +/-2 dB, -12 +/-2 dB @ 10 kHz
Channel: ................................................................... 10 +/-2 dB, below -28 dB @ 70 Hz
....................................................................... 10 +/-2 dB, below -35 dB @ 1 kHz
........................................................................ 10 +/-2 dB, below -28 dB @ 13 kHz

Within 3 dB from 0 to -40 dB

> 85 dB @ 1 kHz for Channel Fader and Crossfader (Master Output: 1 V)

-14 +/-2 dB
