Remak VCS User Manual

59
Control units VCS
List of Data Points (HMI-DM, HMI-TM and HMI@WEB controllers)
Monitor Monitor
Current modes Current modes
ActStateEquipment Current device state
FanStageExtCnt Fan output stage (external control)
FanStatus Fan state
Actual time schedule Current time schedule
CalendarWeek Weekly time schedule
CalendarExcept Exception time schedule
CalendarO Switch-o time schedule
NumbOfFailures Current number of failures
Temperatures Temperatures
Supply Inlet air temperature °C
Room Room temperature °C
Room unit 1 Temperature (HMI-SG1) °C
Room unit 2 Temperature (HMI-SG2) °C
Return air Outlet air temperature °C
Outdoor Outdoor air temperature °C
Return water heat Return water temperature from the water heater °C
Air heat exchanger Outlet air temperature behind the heat exchanger °C
Air electric preheat Temperature behind the electric pre-heater °C
ReturnWaterPreheating Return water temperature from the water pre-heater °C
ExtraElectricHeating Temperature behind the electric after-heater °C
Flue gas Flue gas temperature °C
ValidRegulationRoom Room temperature (for control) °C
Humidity Humidity
Supply air relative Inlet - relative %r.H.
Supply air absolut Outlet - absolute g/kg
Supply air enthalpy Inlet - enthalpy kJ/kg
Room relative Room - relative %r.H.
Room absolut Room - absolute g/kg
Room enthalpy Room - enthalpy kJ/kg
Outs air relative Outdoor - relative %r.H.
Outs air absolut Outdoor - absolute g/kg
Outs air enthalpy Outdoor - enthalpy kJ/kg
Flow (Pressures) Flow (Pressures)
SupplyPress SupplyPress Pa
ReturnPress ReturnPress Pa
SupplyFlow SupplyFlow m3/h
ReturnFlow ReturnFlow m3/h
Air quality Air quality
CO2 (VOC,CO)
CO2
(VOC,
CO) ppm
Outputs Performances
Fan supply output Inlet fan output %
Fan exhaust output Outlet fan output %
Fan additional output Auxiliary fan output %
ExtraElectricalHtgPos Outlet level for the electric reheater %
Heating valve Heating mixing set valve position %
Cooling valve Cooling valve position %
Cooling 2 Cooling valve position 2 %
Cooling 3 Cooling valve position 3 %
Electrical preheating Electric pre-heater outlet position %
ElectricalHeatingValve Electric reheater outlet position %
Heat pump output Heat pump outlet position %
Heat Pump 2 Heat pump outlet position 2 %
Heat Pump 3 Heat pump outlet position 3 %
Mixing section position Outlet position to the mixing damper %
Heat exchanger position Heat exchanger control outlet position %
Gas heating out level Outlet level for the gas heater %
BypassDamperPosition Outlet position for gas heater's BP damper %
Request humidity Request for humication %
Request dehumidity Request for dehumidication %
Working states Operating states
FanSupplyStatus Inlet fan state
FanExhaustStatus Outlet fan state
FanAdditionalStatus Auxiliary fan state
ElectPreheat Electric pre-heater state
WaterPreheat Water pre-heater pump state
ElectReheating Electric re-heater state
PumpOfWaterHeating Pump of water heating
StateHeatExchanger Rotary exchanger State
PrehtgFunctionsWaterHtg Pre-heating functions (water heating)
WaterCoolPump Water cooler pump state
CoolingStDXCool Cooling stage (2St)
CoolInverter Cooling stage (inverter)
ChlazInverter 2 Cooling stage (inverter) 2
ChlazInverter 3 Cooling stage (inverter) 3
Cool1Step Cooling state (1 St + inverter)
HeatPump Heat pump state
ElectricHeater Electric heater state
GasHeater Gas heater state
Menu HMI-DM,HMI-TM a HMI@WEB
Menu Meaning
Factory settings
Value Min Max
Units
