Remak VCS User Manual

60
List of Data Points (HMI-DM, HMI-TM and HMI@WEB controllers)
Menu HMI-DM,HMI-TM a HMI@WEB
Menu Meaning
Factory settings
Value Min Max
Units
StateHumidier Humidier state %
Settings Settings
Date and Time
Date
and
time
TimeValidity System time validity
Temp modes Temperature modes
Comfort - Heating Comfortable heating 22.6 0 99 °C
Comfort - Cooling Comfortable cooling 24.6 0 99 °C
Economic - Heating Economy heating 20.6 0 99 °C
Economic - Cooling Economy cooling 28 0 99 °C
ExSpvSupplyTmp Extra required inlet air temperature 20 0 99 °C
Manual mode Manual mode
Time schedules Time modes
CalendarWeek Weekly time schedule
CalendarExcept Exception time schedule
CalendarO Switch-o time schedule
Control
humidity Humidity control
DehumSpvRel Dehumidication required relative value 60 0 100 %r.H.
DehumSpvAbs Dehumidication required absolute value 12 0 100 g/kg
HumMaxSpv Maximum humidity required value 80 0 100 %r.H.
ActualValueHum Current humidity value
ActCascSpvDeh Calculated current dehumidication required value in cascade control
HumMaxCtlr Maximum humidity %
HumidityCtrl Humidication output
DeHumidityCtrl Dehumidication output %
Dewpoint Dew point current value °C
DewpointDedZone Dew point deviation 1 -64 64 °C
Fans Fans
RegulFans-Flow(Press) RegulFans-Flow(Press)
SupplyPrsRangeSnsr SupplyPrsRangeSnsr
ReturnPrsRangeSnsr ReturnPrsRangeSnsr
SupplyFlowRangeSnsr SupplyFlowRangeSnsr
ReturnFlowRangeSnsr ReturnFlowRangeSnsr
SupplyKFactor SupplyKFactor
ReturnKFactor ReturnKFactor
NmbrOfSplyFans NmbrOfSplyFans
NmbrOfRtrnFans NmbrOfRtrnFans
Enable - K Factor Enable - K Factor
FanSupplyOutputSetpointVal Inlet fan output
Fan output 1. stage % Output settings St1
Fan output 2. stage % Output settings St2
Fan output 3. stage % Output settings St3
Fan output 4. stage % Output settings St4
Fan output 5. stage % Output settings St5
FanExhaustOutputSetpointVal Outlet fan output
Fan output 1. stage % Output settings St1
Fan output 2. stage % Output settings St2
Fan output 3. stage % Output settings St3
Fan output 4. stage % Output settings St4
Fan output 5. stage % Output settings St5
FanAddOutputSetpointVal Additional fan output
Fan output 1. stage % Output settings St1
Fan output 2. stage % Output settings St2
Fan output 3. stage % Output settings St3
Fan output 4. stage % Output settings St4
Fan output 5. stage % Output settings St5
TRN Correct Outlet fan speed TRN correction
ValueOfCorrection For all stages
FanOutputSt1 TRN correction for stage 1
FanOutpuSt2 TRN correction for stage 2
FanOutputSt3 TRN correction for stage 3
FanOutputSt4 TRN correction for stage 4
FanOutputSt5 TRN correction for stage 5
Back-up supply fan Single-speed inlet fan backup
StrtUpDlyFlowMain Failure ow evaluation time-out after main fan start-up 180 0 9999 s
StrtUpDlyFlowBackUp Failure ow evaluation time-out after backup fan start-up 180 0 9999 s
SupplyFanBackUp Active main fan backup
Back-up exhaust fan Single-speed outlet fan backup
StrtUpDlyFlowMain Failure ow evaluation time-out after main fan start-up 180 0 9999 s
StrtUpDlyFlowBackUp Failure ow evaluation time-out after backup fan start-up 180 0 9999 s
ExhaustFanBackUp Active main fan backup
Fan run-out to DEVV Fan run-out according to DEV
Enable Enable run-out
TeplotaVenkovníMin Blocking by the MIN outdoor temperature -15 -64 64 °C
TeplotaVenkovníMax Blocking by the MAX outdoor temperature 5 -64 64 °C
Fan run-out Fan run-out 5 1 60 min
Fan run-out Fan run-out 180 0 9999 s
MinStOnTimeTrans Time transition to 2St speed – two-speed fans 15 0 999 s
