28
List of Data Points (HMI-SG controller)
Monitor
Temperature
°C
001 G Temperature in the inlet °C
002 G Temperature in the room 1 °C
003 G Temperature in the room 2 °C
004 G Room unit 1 °C
005 G Room unit 2 °C
006 G Temperature in the outlet °C
007 G Outdoor temperature °C
008 G Return water temperature °C
009 G Heat exchanger freezing temperature °C
010 G Electric preheater temperature °C
011 G Water preheater temperature °C
012 G Electric reheater temperature °C
013 G Flue gas temperature °C
014 G Final room temperature (controlled) °C
Humidity
015 G Inlet air relative humidity %r.H.
016 G Room air relative humidity %r.H.
017 G Outdoor air relative humidity %r.H.
Pressure
018 G Pressure in the inlet Pa
019 G Pressure in the outlet Pa
020 G Air flow rate in the inlet m3/h
021 G Air flow rate in the outlet m3/h
CO
2
(VOC, CO)
022 G CO
2
(VOC, CO) concentration ppm
Performances
023 G Inlet fan output % (m
3
/h, Pa)
024 G Outlet fan output % (m
3
/h, Pa)
025 G 3rd fan output %
026 G Outlet level for the electric reheater %
027 G Heating mixing set valve position %
028 G Outlet level for cooling %
029 G Cooling output (stage)
030 G Electric preheater position %
031 G Outlet level for the electric heater %
032 G Heat pump output %
033 G Outlet position to the mixing damper %
034 G Heat exchanger control outlet position %
035 G Modulation burner outlet position %
036 G By-pass damper outlet position %
Operating states
037 G Fan state 0 -
1 Stage 1
2 Stage 2
3 Stage 3
4 Stage 4
5 Stage 5
038 G Electric pre-heater state 1 off
2 on
039 G Water pre-heater state 0 off
1 on
040 G Electric re-heater state 1 off
2 on
041 G Water heater pump state 0 off
1 on
042 G Pre-heating function of water heating 0 off
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
