Control units VCS
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
1 on
043 G Water cooler pump state 0 off
1 on
044 G Evaporator cooling stage 1 off
2 Stage 1
3 Stage 2
045 G Inverter cooling stage (inverter) 0 off
1 on
046 G Inverter cooling stage (step1+inverter) 0 off
1 on
047 G Heat pump operating state 0 out of operation
1 cooling
2 heating
048 G Electric heater operating state 1 off
2 on
049 G Gas Burner operating states (stages) 1 off
2 Stage 1
3 Stage 2
Current modes
050 G Fan output stages (external equipment) 0 Auto
1 off
2 Stage 1
3 Stage 2
4 Stage 3
5 Stage 4
6 Stage 5
051 G AHU current operating mode 0 Stop
1 Comfort
2 Economy
3 -
4 Optimized start
5 Night chilling
6 Temperature start-up
7 Night turning
8
9 Fire mode
10 Safety stop
11 Fan run-out
12 Start
Current temperature control values
052 G Calculated required temperature for heating with cascade control °C
053 G Calculated required temperature for cooling with cascade control °C
054 G Calculated required temperature for heating °C
055 G Calculated required temperature for cooling °C
056 G Current temperature-dependent control (inlet, room, outlet) 0 room
1 outlet
2 inlet
Current humidity values
058 G Calculated absolute inlet air humidity g/kg
059 G Calculated inlet air humidity enthalpy kJ/kg
060 G Calculated absolute room air humidity g/kg
061 G Calculated room air humidity enthalpy kJ/kg
062 G Calculated absolute outdoor air humidity g/kg
063 G Calculated outdoor air humidity enthalpy kJ/kg
064 G Request for dehumidification %
065 G Request for humidification %
