Remak VCS User Manual

30
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
066 G Humidifier state 0 off
1 on
Settings
Temperature modes
101 A 102 G Comfort - cooling 24.6 0 99 °C
103 A 104 G Comfort - heating 22.6 0 99 °C
105 A 106 G Economy - cooling 28 0 99 °C
107 A 108 G Economy - heating 20.6 0 99 °C
109 A 110 G Required temperature for cooling, Temperature start-up 15 -64 64 °C
111 A 112 G Required temperature for heating, Temperature start-up 25 -64 64 °C
113 A 114 G Required room temperature , Night chilling (control for inlet) 22 -64 64 °C
115 A 116 G Required room temperature , Boost (control for inlet) 20 -64 64 °C
117 A 118 G Required temperature for cooling, Boost 15 -64 64 °C
119 A 120 G Required temperature for heating, Boost 25 -64 64 °C
Cascade control limitation - limiter
121 S 122 A Max. difference between room temperature and inlet temperature 10 0 64 °C
123 S 124 A Min. difference between room temperature and inlet temperature 10 0 64 °C
Operation mode
125 A 126 G AHU manual control (Temperature mode, fan output stage) 0 Auto Stop
1 Stop
2 Economy; St1
3 Comfort; St1
4 Economy; St2
5 Comfort; St2
6 Economy; St3
7 Comfort; St3
8 Economy; St4
9 Comfort; St4
10 Economy; St5
11 Comfort; St5
127 A 128 G AHU start-up time-out aer power supply failure 10 0 9999 s
External control
129 U 130 G External contact function definition (Ext. control 1 contact) 0 Start function 0
1 Start and Stop function
131 U 132 G
Transition time from ext. control mode to AUTO mode (Ext. control 1
contact)
0 0 23 h
133 U 134 G Fan output stage setting (Ext. control 1 contact or 2 contacts) 0 Auto 2
1 off
2 Stage 1
3 Stage 2
4 Stage 3
5 Stage 4
6 Stage 5
135 U 136 G Temperature mode setting (Ext. control 1 contact or 2 contacts) 0 Comfort 0
1 Economy
137 U 138 G Fan output stage setting "Higher" (Ext. control 2 contacts) 0 Auto 5
1 off
2 Stage 1
3 Stage 2
4 Stage 3
5 Stage 4
6 Stage 5
139 U 140 G Temperature mode setting "Higher" (Ext. control 2 contacts) 0 Comfort 0
1 Economy
Fans - Modbus
Control limits
141 A Inlet fan output St1 setting 0.1 % (m
3
/h, Pa)
