Remak VCS User Manual

31
Control units VCS
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
142 A Inlet fan output St1 setting (a factor of 10) % (m
3
/h, Pa)
143 A Inlet fan output St2 setting 25 % (m
3
/h, Pa)
144 A Inlet fan output St2 setting (a factor of 10) % (m
3
/h, Pa)
145 A Inlet fan output St3 setting 50 % (m
3
/h, Pa)
146 A Inlet fan output St3 setting (a factor of 10) % (m
3
/h, Pa)
147 A Inlet fan output St4 setting 75 % (m
3
/h, Pa)
148 A Inlet fan output St4 setting (a factor of 10) % (m
3
/h, Pa)
149 A Inlet fan output St5 setting 100 % (m
3
/h, Pa)
150 A Inlet fan output St5 setting (a factor of 10) % (m
3
/h, Pa)
151 A Outlet fan output St1 setting 0.1 % (m
3
/h, Pa)
152 A Outlet fan output St1 setting (a factor of 10) % (m
3
/h, Pa)
153 A Outlet fan output St2 setting 25 % (m
3
/h, Pa)
154 A Outlet fan output St2 setting (a factor of 10) % (m
3
/h, Pa)
155 A Outlet fan output St3 setting 50 % (m
3
/h, Pa)
156 A Outlet fan output St3 setting (a factor of 10) % (m
3
/h, Pa)
157 A Outlet fan output St4 setting 75 % (m
3
/h, Pa)
158 A Outlet fan output St4 setting (a factor of 10) % (m
3
/h, Pa)
159 A Outlet fan output St5 setting 100 % (m
3
/h, Pa)
160 A Outlet fan output St5 setting (a factor of 10) % (m
3
/h, Pa)
161 A 162 U 3rd fan output St1 setting 0.1 0.1 100 %
163 A 164 U 3rd fan output St2 setting 25 0.1 100 %
165 A 166 U 3rd fan output St3 setting 50 0.1 100 %
167 A 168 U 3rd fan output St4 setting 75 0.1 100 %
169 A 170 U 3rd fan output St5 setting 100 0.1 100 %
171 A 172 U Fan run-out aer unit stop shut-down 180 0 9999 s
570 A
Enabling the fan run-out according to DEV 0 No 1
1 Yes
571 A
Unit run-out – blocking by the minimum outside temperature -15 -64 64 °C
572 A
Unit run-out – blocking by the maximum outside temperature 5 -64 64 °C
573 A
Unit run-out – time 5 1 60 Min
Inlet backup – single-speed motors
173 A 174 U Failure flow evaluation time-out aer main fan start-up 180 0 9999 s
175 A 176 U Failure flow evaluation time-out aer backup fan start-up 180 0 9999 s
181 U Information – backup activation 0 non-activated
1 activated
Outlet backup - single-speed motors
177 A 178 U Failure flow evaluation time-out aer main fan start-up 180 0 9999 s
179 A 180 U Failure flow evaluation time-out aer backup fan start-up 180 0 9999 s
182 U Information - backup activation 0 non-activated
1 activated
TRN correction
183 A 183 A Common for all operating stages St 0 - 4 stages 0
1 - 3 stages
2 - 2 stages
3 - 1 stage
4 0
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
184 A 184 A For operating stage St1 0 - 4 stage 0
1 - 3 stage
2 - 2 stage
3 - 1 stage
4 0
