List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
185 A 185 A For operating stage St2 0 - 4 stage 0
1 - 3 stage
2 - 2 stage
3 - 1 stage
4 0
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
186 A 186 A For operating stage St3 0 - 4 stage 0
1 - 3 stage
2 - 2 stage
3 - 1 stage
4 0
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
187 A 187 A For operating stage St4 0 - 4 stage 0
1 - 3 stage
2 - 2 stage
3 - 1 stage
4 0
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
188 A 188 A For operating stage St5 0 - 4 stage 0
1 - 3 stage
2 - 2 stage
3 - 1 stage
4 0
5 + 1 stage
6 + 2 stages
7 + 3 stages
8 + 4 stages
TRN – fan start-up (without outlet for dampers)
189 S 189 S Forced fan start-up time setting to Stage 1 20 0 99 s
Two-speed motors
190 A 191 U Transition time interval from speed 1 to speed 2 15 0 999 s
192 A 193 U Transition time-out from speed 2 to speed 1 12 0 99 s
Inlet temperature limitation
194 S 194 S Minimum inlet air temperature 15 0 64 °C
195 S 195 S Maximum inlet air temperature 35 0 64 °C
Additional operating modes, functions
196 S 196 S Outdoor temperature dependent fan speed compensation 0 No 0
1 Yes
197 S 197 S Heating/cooling dependent fan speed compensation 0 No 0
1 Heating
2 Cooling
