Control units VCS
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
3 Heating + Cooling
198 S 198 S Air quality dependent fan speed compensation 0 No 1
1 Yes
199 S 199 S Room (outlet) temperature dependent fan speed compensation 0 No 0
1 Yes
230 S 230 S Humidity-dependent fan speed compensation 0 No 0
1 Yes
231 S 231 S Limitation of dehumidification during heating 0 No 0
1 Yes
201 S 201 S Difference between required and actual temperature monitoring 0 No 0
1 inlet
2 room
3 Inlet+room
202 S 202 S Air quality dependent damper position compensation 0 No 0
1 Yes
246 S 246 S Humidity-dependent mixing damper position compensation 0 No 0
1 Yes
247 S 247 S Max. limit of fresh air according to T outdoor (ventilation unit) 0 No 0
1 Yes
203 S 203 S Cooling using HR (RHE, BP PE, mixing damper) 0 without HR cooling 3
1 RHE, BP PE
2 mixing damper
3 RHE+ damper
204 S 204 S
Heating/cooling dependent fan speed compensation-cooling sequence
(fan, cooler)
0 fan+cooler 1
1 cooler+fan
205 S 205 S Mixing heating sequence (damper, heater) 0 damper+heater 0
1 heater+damper
206 S 206 S Night cooling 0 without chilling
1 with chilling
207 S 207 S Temperature start-up 0 N/A 0
1 heating
2 cooling
3 heating + cooling
208 S 208 S Time mode start optimization 0 N/A 0
1 heating
2 cooling
3 heating + cooling
209 S 209 S Damper and outlet fan blocking 0 N/A 0
1 dampers
2 dampers+fan
210 S 210 S Outlet fan correction type (TRN controllers) 0 separate stages 0
1 shared stages
211 S 211 S Reset aer configuration of additional modes/functions 0 without reset
1 reset
212 S 212 S Room temperature measuring point selection 0 average 3
1 minimum
2 maximum
3 room temp. sensor 1
4 room temp. sensor 2
5 HMI-SG 1 controller
6 HMI-SG 2 controller
Control signal characteristic
213 A 213 A Control signal 0-10 V or 2-10 V, heating 0 0-10V
1 2-10V 1
214 A 214 A Control signal 0-10 V or 2-10 V, cooling 0 0-10V
1 2-10V 1
215 A 215 A Control signal 0-10 V or 2-10 V, mixing damper 0 0-10V
1 2-10V 1
