Remak VCS User Manual

34
List of Data Points (HMI-SG controller)
Menu HMI-SG
Parameter
Meaning
Factory Settings
Notation Reading Value Min Max
code level code level
216 A 216 A Control signal 0-10 V or 2-10 V, heat exchanger by-pass damper 0 0-10V
1 2-10V 1
217 A 217 A Control signal 0-10 V or 2-10 V, chamber by-pass damper 0 0-10V
1 2-10V 1
Required inlet temperature extra set-point
218 A 219 G
Required inlet temperature extra set-point (applied when el. re-heating or
heat pump is removed from the main sequence)
20 0 99 °C
220 S 220 S Fan start-up delay (aer damper) 20 0 9999 s
221 S 221 S
Outdoor-dependent fan speed interlocking
-60 -64 64 °C
Control – Flow (Pressure)
222 A 223 U Setting range of flow sensor - inlet (a factor of 100) 8000 0 2*105 m3/h
224 A 225 U Setting range of flow sensor - outlet (a factor of 100) 8000 0 2*105 m3/h
226 A 227 U Setting range of pressure sensor - inlet (a factor of 100) 6000 0 7000 Pa
228 A 229 U Setting range of pressure sensor - outlet (a factor of 100) 6000 0 7000 Pa
232 A 233 U K factor – inlet 95 0 9999
234 A 235 U K factor – outlet 95 0 9999
236 A 237 U NunberInletFan 1 1 100
238 A 239 U NunberOutletFan 1 1 100
240 S K Factor - Enabled 0 No
1 Yes 1
Inputs configuration
241 S Reverse function of fault input for Cooling or Heat Pump 0 Normal 0
1 Reversed
Device configuration
270 U Regulation supply fan 0 none
1 1 stage
2 5 stage (TRN)
3 V10
4 V100
5 V10 + back-up
6 V100 + back-up
7 2xV10
8 2xV100
9 2xV10 + back-up
10 2xV100 + back-up
271 U Regulation exhaust fan 0 none
1 1 stage
2 5 stage (TRN)
3 V10
4 V100
5 V10 + back-up
6 V100 + back-up
7 2xV10
8 2xV100
9 2xV10 + back-up
10 2xV100 + back-up
272 U Regulation additional fan 0 none
1 1 stage
2 5 stage (TRN)
3 V10
4 V100
7 2xV10
8 2xV100
273 U Heating 0 no
1 water
2 electric
3 gas
