Control units VCS
List of Data Points (HMI-DM, HMI-TM and HMI@WEB controllers)
Menu HMI-DM,HMI-TM a HMI@WEB
Menu Meaning
Factory settings
Value Min Max
Units
PropFactor Proportional factor -5
IntegFactor Integrating factor 0 s
DierFactor Derivative factor 0 s
HrecDampCompHumidity Humidity-dependent mixing damper position compensation factors
PropFactor Proportional factor -2
IntegFactor Integrating factor 45 s
DierFactor Derivative factor 0 s
CompensationAirQuality
Air quality CO2(VOC,CO)-dependent compensa-
tion (damper position/fan speed) factors
PropFactor Proportional factor -0.3
IntegFactor Integrating factor 300 s
DierFactor Derivative factor 0 s
SplyFanVarCtlr SplyFanVarCtlr
PropFactor PropFactor -0.3
IntegFactor IntegFactor 30 s
DierFactor DierFactor 0 s
ExhFanVarCtlr ExhFanVarCtlr
PropFactor PropFactor -0.3
IntegFactor IntegFactor 30 s
DierFactor DierFactor 0 s
Device conguration Device conguration
Aplication info Application information
Device Info Device information
Unit °C → °F Change units from Metric to imperial
Version OS OS version
InternTempRegulator Controller internal temperature
Operating Hours Operating hours
Type of device Device type
Inputs conguration Inputs conguration
HeatPumpAlm Heat Pump Fault
Cooling alarm Cooling Fault
Output conguration Output conguration
Signal type heating Control signal 0-10 V or 2-10 V, heating
Signal type cooling Control signal 0-10 V or 2-10 V, cooling
Signal type mix damper Control signal 0-10 V or 2-10 V, mixing damper
SignalTypByPassHeatRec Control signal 0-10 V or 2-10 V, heat exchanger by-pass damper
SignalTypeByPassBurn Control signal 0-10 V or 2-10 V, chamber by-pass damper
RegulationSupplyFan Type of regulation supply fan
RegulationExhaustFan Type of regulation exhaust fan
RegulationAddtionalFan Type of regulation additional fan
Heating Heating
Heat pump Heat pump
Gas heat type Type of gas heating
GasHeaterBypassDamp Byppas damper gas heater
Cooling Cooling
Heat recovery Heat recovery
Mixing Mixing
Preheating Preheating
Extra heating Extra heating
TemperatControlMode Temperature control mode
HumidityControlMode Humidity control mode
RemoteFault-ClassFault Remote fault - choice class fault
Version SW-HMI SW-HMI version
AditionalOperModeAndFunction Additional operating modes, functions
TemperatureMeasurePointSelect Room temperature measuring point selection
FanCompensationOutTemperature Outdoor Temperature-Dependent Fan Speed Compensation
Fan compensation sequence Heating/cooling dependent fan speed compensation
Fan compensation air quality Air quality-dependent fan speed compensation
FanCompensationRoomExhaustTmp Room (outlet) temperature-dependent fan speed compensation
Temperature deviation alarm Dierence between required and actual temperature monitoring
AntiFreezeDEV DEV Water Heater Antifreeze Protection Variant
HeatRecoveryCompensationAirQ Air quality-dependent damper position compensation
Heat recovery cooling Cooling using ZZT (ROV, BP, DEV, mixing damper)
Fan cooling sequence
Heating/cooling dependent fan speed compen-
sation-cooling sequence (fan, cooler)
HeatRecovery-
DamperSequence Mixing heating sequence (damper, heater)
Night coolling Night chilling
Temperature start-up Temperature start-up
Boost Time mode start optimization
BlockedDamper-
AndExhaustFan Damper and outlet fan blocking
Type corrrect TRN
exhaust fan Outlet fan correction type (TRN controllers)
LimitationDeHu-
midiForHeating Limitation of dehumidication during heating
Humidity fan
compensation Humidity-dependent fan speed compensation
Humidity HrecDampCompensation Humidity-dependent mixing damper position compensation
