96
Connection to the Master System (BacNet Standard)
OpModeBmsTimeSt.Swtch BMS control mode (control, master system)
OpModeBmsTimeStTmp.Swtch BMS control mode (control, master system)
TmpSpv.CoSpvHtg Required value for heating - Comfort
TmpSpv.CoSpvClg Required value for cooling - Comfort
TmpSpv.EcSpvHtg Required value for heating - Economy
TmpSpv.EcSpvClg Required value for cooling - Economy
HumSpvRel.SpvHum Required value for humidification (relative)
HumSpvRelSpvDehum Required value for dehumidification (relative)
AirQSpv Required value for air quality
ScheduleSt Weekly time schedule
ScheduleStTmp Weekly time schedule
CalendarEx Exception time schedule
CalendarOff Switch-off schedule
ActCascSpvHtg Current required heating temperature (cascade)
ActCascSpvClg Current required cooling temperature (cascade)
ActCascSpvDeh Current required value for dehumidification (cascade)
ActCascSpvHum Current required value for humidification (cascade)
Heating.Pos Heating node valve outlet position
ElectricalHtg.Pos Electric heating outlet position
Cooling.Pos Cooling valve outlet position
ExtraElHtg.Pos Electric aer-heating outlet position
Hrec.Pos Heat exchanger control outlet position
HrecDamp.Pos Mixing damper outlet position
aoHeatPumpHtg.Pos Heat pump outlet position - heating
aoHeatPumpClg.Pos Heat pump outlet position - cooling
HumidityCtrl.Pos Humidification current value
DeHumidity.PrVal Dehumidification current value
AirQCmp.PrVal Air quality compensation current value
SplyFan.Cmd.St Current stage, inlet fan
ExhFan.Cmd.St Current stage, outlet fan
Heating.Pmp.Cmd.OnOff Heating pump state
ElectricalHtg.CmdSt.St Electric heater state
ExtraElHtg.CmdSt.St Electric aer-heater state
Cooling.Pmp.Cmd.OnOff Water cooler pump state
Cooling.CmdDx.St Cooling state, inverter cooling unit
Damper.Exh.OnOff Damper, outlet
Damper.Sply.OnOff Damper inlet
AlmOutHigh Alarm, output A
AlmOutLow Alarm, output B
AlmCl0 Alarm, class A
AlmCl1 Alarm, class A
AlmCl2 Alarm, class B
AlmCl3 Alarm, class B
FireAlm External alarm
AckAlmPls Failure release
List and Description of Basic Data Points ((continuation))
