13.4 Spare parts list - Outdoor unit
IMPOR
TANT!
To ensure the correct delivery of spare parts, please always the device type with the corresponding serial
number (see type plate)
No. Designation
1 Front panel, left
2 Protection grid, front plate
3 Fan blade
4 Fan motor
5 Fan motor bracket
6 Corner panel
7 Housing cover
8 Base plate
9 Partitioning panel
10 Air probe condenser
11 Condenser
12 Condenser pipe placement probe
13 Inductor
14 Control board
15 Shut-off valve, injection pipe
16 Side section, housing, right
17 Plastic covering, terminal block
18 Plastic covering, pipe connections
19 Shut-off valve, suction pipe
20 4-way valve
21 Compressor pipe placement probe
22 Compressor
23 Crankcase heating
24 Condensate tray heating
