NU760_1_G5-FRA.qxd 10/11/05 8:35 Page 5.16
REAR LIGHTS: changing bulbs (continued)
5.16
Bottom light unit B
Open the tailgate and remove the
bolts 7 (using a screwdriver from the
luggage compartment) and remove
the wheel trim.
Turn the bulb holder 9 one quarter-
turn and take out the bulb.
Rear fog light
Bayonet bulb: P21W.
Undo screws 8.
Take out the unit by turning it.
The bulbs are under
pressure and can break
when changed. Risk of
injury.
NU760_1_G5-ENG.qxp 27-Dec-05 18:44 Page 5.16 (Black/Process Black plate)
