WINDSCREEN WIPER BLADES
- In frosty weather, make
sure that the wiper
blades are not stuck by
ice (risk of motor
overheating).
- Check the condition of the wiper
blades. Replace the wiper blades
as soon as they begin to lose
efficiency (approximately once a
year).
Replacing windscreen wiper
blades 1
- Lift wiper arm 2;
- fold the blade 1 down into a
horizontal position;
- slide the blade 1 until the catch 3 is
released on the windscreen wiper
arm.
To refit
To refit the wiper blade, proceed in
reverse order to removal. Make sure
that the blade is correctly locked in
position.
Rear screen wiper 4
- Lift wiper arm 5 until it locks;
- pivot blade 4 until it unclips from
its shaft.
To refit
Clip the blade to the shaft to refit the
wiper blade. Make sure that the
blade is correctly locked in position.
Windscreen washer jets
These can be adjusted using a tool
such as a flat-blade screwdriver.
