NU760_1_G1-FRA.qxd 10/11/05 10:10 Page 1.40
1.40
CHILD SAFETY (continued)
Fitting child seats
- Before fitting and using the seat,
read the instructions provided
carefully;
- secure guides 1 (supplied with the
seat or sold separately) to
anchoring rings 2;
- slide seat catches 3 into guides 1
and push the seat firmly to lock it
on rings 2;
- check that the seat is locked
correctly (by moving it from left to
right and then forwards and
backwards).
Seatback mounting ring for a
forward-facing seat
- Pass belt 4 (supplied with the
seat) between the two rear
headrest rods;
- attach hook 5 to ring 6.
Seatback mounting ring for a rear-
facing seat
Attach hook 5 to ring 7.
Labels on locks 2 allow you to
mark them.
