24046
6a
6
7
8
NU760_1_G1-FRA.qxd 10/11/05 10:10 Page 1.51
1.51
INSTRUMENT PANEL: displays and indicators (continued)
Coolant temperature indicator 6
In normal use, the level must be
below zone 6a. Under severe
conditions the needle may approach
this zone. But the situation is not
serious unless the
û
warning
light lights up, accompanied by an
engine overheating message on the
instrument panel, a beep and
warning light 6a.
Fuel level gauge 7
The number of lit squares shows the
remaining fuel level.
When it is at minimum, the bottom
square lights up and flashes. Then a
beep will be heard: refill as soon as
possible.
Information display 8
Depending on the vehicle, it
includes:
- the time,
- the exterior temperature,
- radio signals,
- navigation aid information.
