1.36
CHILD SAFETY (continued)
Rear-facing seat mounting ring for
rear seats
- depending on the vehicle, recentre
the rear bench (refer to the
information on rear bench seat
functions in Section 3), and move
it back fully;
-attachthefrontseatbelthookto
ring 5 or, depending on the
vehicle, ring 6 (located under the
rear bench seat base or on the
floor) and marked by a label;
- tighten the belt.
Front-facing seat mounting ring
(rear seats only)
- depending on the vehicle, move
the bench seat back fully;
-pass strap 4 (supplied with the
seat) between the two rear
headrest rods,
- attach hook 7 to ring 8, located on
the roof rear cross member,
marked by a label next to the ring,
- tighten the belt.
