4.2.8.4 Ethernet Interface RH850/F1H, F1KM-S4 and F1KH/D8 version only)

Ethernet PHY (IC6) is supplied to provide an external T100Base-TX Ethernet bus interface. The

transceiver can be connected to the microcontroller’s Ethernet interface ETNB via the DIP

switches ETH1 – ETH3.

Please use the following DIP switch configuration to connect the Ethernet transceiver to the

microcontroller:

Switch

Setting

Note

ETH1

1 on

ETH0LINK ↔ P18_0

2 on

ETH0TXD0 ↔ P18_1

3 on

ETH0TXD1 ↔ P18_2

4 on

ETH0TXD2 ↔ P18_3

5 on

ETH0TXD3 ↔ P18_4

6 on

ETH0TXEN ↔ P18_5

7 on

ETH0TXERR ↔ P18_6

8 on

ETH0TXCLK ↔ P18_7

Table 31. DIP Switch ETH1

Switch

Setting

Note

ETH2

1 on

ETH0RXCLK ↔ P10_0

2 on

ETH0RXD0 ↔ P10_1

3 on

ETH0RXD1 ↔ P10_2

4 on

ETH0RXD2 ↔ P10_4

5 on

ETH0RXD3 ↔ P10_5

6 X No function

Table 32. DIP Switch ETH2

Switch Setting Note

ETH2

1 on

ETH0RESETB ↔ P11_9

2 on

ETH0COLSD ↔ P11_10

3 on

ETH0RXDV ↔ P11_11

4 on

ETH0CRS ↔ P11_13

5 on

ETH0RXERR ↔ P11_14

6 on

ETH0MDIO ↔ P12_4

7 on

ETH0MDC ↔ P12_5

8 on

ETH0INT ↔ P11_6

Table 33. DIP Switch ETH3
