Renesas RH850/F1Kx Series User Manual

Y-RH850-F1X-100PIN-PB-T1-V3 User’s Manual
R20UT3959ED0101, Rev. 1.01 6
2019-11-27
Chapter 2 Overview
2.1 Overview
Figures 1 and 2 provide the views of the RH850-F1X-100PIN-PB-T1-V3
Piggyback Board.
Figure 3 – RH850-F1X-100PIN-PB-T1-V3 top view
Figure 4 – RH850-F1X-100PIN-PB-T1-V3 bottom view
Device pin #1
