Table 1-2 Debugging Function List
Item
Type of the RL78 Core
Description
RL78-S2
RL78-S3
Memory reference or change during program execution
Pseudo-real-time RAM monitor
(RRM)
Supported
Supported
CPU is used when monitoring
Dynamic Memory Modification
(DMM)
Supported Supported CPU is used when changing
Event
1 point
2 points
(max)
Can be used for hardware break
(or trace*1)
Break Software break Supported Supported 2000 points
Hardware break
Supported
Supported
Execution address or data access
Forced break Supported Supported
Trace
Acquired information
Not
supported
Supported
*2
Branch source PC information
Start event
Not
supported
Supported
*2
User program execution start and event
start
End event
Not
supported
Supported
*2
User program stop, event completion, and
full trace memory
Performance
measurement
function
Measurement item Supported Supported
Between start and stop of user program
execution
Performance
Supported
Supported
Resolution: 100 μs
Maximum measurement time: 119 hours
18 min
Hot plug-in
Not
supported
Supported
*3
Coverage measurement function
Not
supported
Not
supported
Extended
function of the
E2
Solution for the
tuning of current
consumption
Supported Supported
Current consumption by the user system is
measured when the power is supplied from
the E2.
External trigger
input/output
Supported
Supported
External triggers can be input to or output
from the E2 expansion interface.
Notes: 1. Only devices in which the trace function was implemented.
2. The trace function is not supported in an RL78/G14 MCU whose ROM size is 64 Kbytes or less. The trace
function is also not supported for RL78/G11, RL78/G1G, and RL78/FGIC MCUs.
3. Only RL78/F1x series(except F12), RL78/F2x
