RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1012
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
CSI mode connection diagram (during communication at same potential)
User's device
SCKp
SOp
SCK
SI
SIp SO
RL78/G13
CSI mode serial transfer timing (during communication at same potential)
(When DAPmn = 0 and CKPmn = 0, or DAPmn = 1 and CKPmn = 1.)
SIp Input data
Output data
SOp
t
KCY1, 2
t KL1, 2
t KH1, 2
t SIK1, 2
t KSI1, 2
t KSO1, 2
SCKp
CSI mode serial transfer timing (during communication at same potential)
(When DAPmn = 0 and CKPmn = 1, or DAPmn = 1 and CKPmn = 0.)
SIp Input data
Output data
SOp
t
KCY1, 2
t KH1, 2
t KL1, 2
t SIK1, 2
t KSI1, 2
t KSO1, 2
SCKp
Remarks 1. p: CSI number (p = 00, 01, 10, 11, 20, 21, 30, 31)
2. m: Unit number, n: Channel number (mn = 00 to 03, 10 to 13)
