RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1035
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
(4) When AV
REF (+) = Internal reference voltage (ADREFP1 = 1, ADREFP0 = 0), AVREF (−) = AVREFM/ANI1 (ADREFM =
1), target ANI pin : ANI0 to ANI14, ANI16 to ANI26
(T
A = −40 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V, Reference voltage (+) = VBGR,
Reference voltage (−) = AVREFM = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 bit
Conversion time tCONV 8-bit resolution 2.4 V ≤ VDD ≤ 5.5 V 17 39
μ
s
Zero-scale error
Notes 1, 2
EZS 8-bit resolution 2.4 V ≤ VDD ≤ 5.5 V ±0.60 %FSR
Integral linearity error
Note 1
ILE 8-bit resolution 2.4 V ≤ VDD ≤ 5.5 V ±2.0 LSB
Differential linearity error
Note 1
DLE 8-bit resolution 2.4 V ≤ VDD ≤ 5.5 V ±1.0 LSB
Reference voltage (+) VBGR 1.38 1.45 1.5 V
Reference voltage (−) AVREFM VSS V
Analog input voltage VAIN 0 VBGR V
Notes 1. Excludes quantization error (±1/2 LSB).
2. This value is indicated as a ratio (%FSR) to the full-scale value.
To Next Page
