RL78/G13 APPENDIX A REVISION HISTORY
R01UH0146EJ0100 Rev.1.00 1070
Sep 22, 2011
(2/2)
Edition Description Chapter
Change of note 2 in Figure 6-8. Format of Timer Mode Register mn (TMRmn)
(4/4)
Change of 6. 3 (6) Timer channel start register m (TSm)
Change of Figure 6-42. Operation Procedure of Interval Timer/Square Wave
Output Function (2/2)
Change of Figure 6-46. Operation Procedure When External Event Counter
Function Is Used
Change of Figure 6-50. Operation Procedure When Frequency Divider Function
Is Used
Change of Figure 6-62. Operation Procedure When Delay Counter Function Is
Used
Change of Figure 6-67. Operation Procedure of One-Shot Pulse Output
Function (2/2)
Change of Figure 6-72. Operation Procedure When PWM Function Is Used (2/2)
Change of Figure 6-77. Operation Procedure When Multiple PWM Output
Function Is Used (2/2)
CHAPTER 6 TIMER
ARRAY UNIT
Addition of cautions to Figure 19-5. Format of Reset Control Flag Register
(RESF)
CHAPTER 19 RESET
FUNCTION
Addition of caution to Figure 22-6. Format of RAM Parity Error Control Register
(RPECTL)
CHAPTER 22
SAFETY FUNCTIONS
Change of Table 25-1. Wiring Between RL78/G13 and Dedicated Flash Memory
Programmer
Change of Figure 25-2. Communication with Dedicated Flash Memory
Programmer
Change of Table 25-2. Pin Connection
Change of description of 25.4.1 Data flash overview
Change of description of 25.5.2 Flash memory programming mode
Change of Table 25-7. Flash Memory Control Commands
Addition of caution to 25.7 Flash Memory Programming by Self-Programming
CHAPTER 25 FLASH
MEMORY
Ver.0.07
Change of 29.10 Timing Specs for Switching Modes
CHAPTER 29
ELECTRICAL
SPECIFICATIONS
(TARGET)
